NVIDIA Mellanox ConnectX-6 Dx 100GbE Dual-Port QSFP56 OCP 3.0 Adapter
MCX623436AN-CDABAvailable to order
NVIDIA Mellanox ConnectX-6 Dx EN SmartNIC in the OCP 3.0 small form factor, with two QSFP56 ports supporting 10, 25, 40, 50 and 100 Gb/s Ethernet. PCIe Gen3/Gen4 x16 host interface at 8.0/16.0 GT/s, with host management and a thumbscrew pull-tab bracket. Hardware offloads for RoCE, SR-IOV, overlay networks, stateless TCP and NVMe-oF cover SDN/NFV, virtualisation, storage and machine-learning fabrics. This is the AN variant, supplied without the inline crypto and secure-boot engine of the AC part.
- Family
- ConnectX-6 Dx EN
- Ports
- 2× QSFP56
- Max Port Speed
- 100 Gb/s
- Ethernet Speeds
- 10/25/40/50/100G
- Form Factor
- OCP 3.0 SFF
- PCI Express
- Gen3 / Gen4 x16
- SerDes Rate
- 8.0 / 16.0 GT/s
- Host Management
- Supported
- Bracket
- Thumbscrew pull-tab
- RDMA
- RoCE v1 / v2
- Virtualisation
- SR-IOV
- Overlay
- VXLAN, GENEVE
- Stateless
- TCP/UDP/IP offload
- Storage
- NVMe-oF target
- Timing
- PTP hardware clock
- Variant
- AN — no crypto
- Secure Boot
- Not on this SKU
- IPsec / TLS Inline
- AC variant only
Adapter
Host Interface
Offloads
Security
